Product Info for Garmin echo 150 Fishfinder
Garmin echo 150 Fishfinder 010-00951-00 is the sport fisherman's dream! Garmin has managed to package dual-beam technology at a single-beam price. This Garmin Fishfinder is powered with 200 watts (RMS) of sonar power, giving you the capability of accurately scanning depths of 1,300 feet in freshwater lakes. In a more shallow area, a viewing angle of up to 120° will allow you to see fish well beyond the sides of your boat. This fish finder was designed with a Garmin exclusive HD-ID target tracking technology, which provides better separation and definition of images on a crisp 4-in grayscale display. The included quick release mount and versatile transom-mount transducer make installation simple and easy. The compact design of the Garmin echo150 Fishfinder will keep it out of your way all day long, even on smaller craft.
Specifications for Garmin echo 150 Fish Finder 010-00951-00:
| Physical & Performance | ||
|---|---|---|
| Unit dimensions, WxHxD: | 4.1" x 5.8" x 2.8" (10.4 x 14.7 x 7.1 cm) | |
| Display size, WxH: | 2.38" x 3.21" (6.04 x 8.15 cm); 4" diag, (10.16 cm) | |
| Display resolution, WxH: | 160 x 256 pixels | |
| Display type: | 8-level grayscale FSTN | |
| Weight: | 9.5 oz (270 g) | |
| Waterproof: | yes (IPX7) | |
| Features | ||
| Audible alarms: | yes | |
| Dual-frequency sonar capable: | no | |
| Dual-beam sonar capable: | yes | |
| Split-screen zoom: | no | |
| Ultrascroll (displays fish targets at higher boat speeds): | yes | |
| Fish Symbol ID (helps identify fish targets): | yes | |
| AutoGain Technology (minimizes clutter, maximizes targets): | yes | |
| Whiteline (indicates hard or soft bottom): | yes (always on) | |
| Adjustable depth line (measures depth of underwater objects): | no | |
| A-scope (real time display of fish passing through transducer beam): | no | |
| Bottom lock (shows return from the bottom up): | no | |
| Water temperature log and graph: | no | |
| Water temperature sensor included: | yes | |
| Water speed capable (displays speed on water): | no | |
| Other | ||
| Frequency: | 200/77 kHz | |
| Transmit power: | 200W (RMS)/1,600W (peak to peak) | |
| Voltage range: | 10V - 20V input | |
| Maximum depth: | 1,300 ft freshwater* | |
| Cone angle: | 60° or 120° (dual beam) | |
Features of Garmin echo 150 Fishfinder 0100095100:
- Garmin HD-ID technology
- 200 watts (RMS) transmit power
- Depths to 1,300 ft*
- Beam width to 120 degrees
- 4 in, 8-level FSTN grayscale display
- Includes tilt/swivel mount, transducer, trolling motor clamp and transom mount
- *Depth capacity is dependent on water bottom type and other water conditions
Package Contents:
- Garmin echo 150 Fishfinder 010-00951-00
- Quick release mount with tilt and swivel
- Power cable
- Transducer w/ mounting bracket, hardware and trolling motor clamp
- Documentation
Be the first to review this product
Garmin echo 150 Fishfinder Unavailable & Discontinued Models
List of Unorderable Models
- Garmin echo 150 Fishfinder 010-00951-00 , MPN: ECHO 150 , UPC: 753759969929 , Code: GA-FH-010-00951-00
