Garmin echoMAP Sonar 55DV with Transducer 010-01385-00,
Tap Tap to Zoom
Product No Longer Available
Unfortunately Garmin echoMAP Sonar 55DV with Transducer is not listed by CampSaver.You can also explore other items in the Fishing, Boating & Marine, Fishing Marine Electronics, Fishfinders yourself to try and find the perfect replacement for you!
Product Info for Garmin echoMAP Sonar 55DV with Transducer
The perfect way to navigate the mysterious depths of Canadian lakes, the Garmin echoMAP Sonar 55DV with Transducer ensures that you are fully informed about anywhere you decide to boat or fish. Easy to install and even easier to use, this Sonar System from Garmin clips on to the quick release mount and locates your boat almost instantly using the 5 Hz Internap GPS. Offering both traditional HD-ID sonar and DownVu scanning sonar options, the Garmin echoMAP Freshwater Sonar 55DV with Transducer allows you to clearly see what is below your boat in real time, allowing you to easily find where all the fish are hiding. With sonar recording and data share between devices, you'll never forget where you found your big haul when you use the Garmin echoMAP Canadian Sonar 55DV with Transducer.
Specifications for Garmin echoMAP LakeVu Sonar 55DV with Transducer:
| Dimensions: | 6.8" x 5.4" x 1.7" (17.3 x 13.6 x 4.4 cm) |
| Weight: | 1.3 lbs (0.6 kg) |
| Water Rating: | IPX7 |
| Power Supply Range: | 10V - 20V DC |
| Typical Power Consumption: | 7.1 W |
| Digital Size (diagonal): | 5.0" |
| Display Resolution: | 480 x 480 square |
| Preloaded Maps: | Canada LakeVu HD |
| Internal 5 Hz GPS Receiver: | Y |
| Dual Frequency (50/200 kHz) capable: | Y |
| Dual Beam (77/200 kHz) capable: | Y |
| DownVu capable: | Y |
| SideVu capable: | N |
| Trasmit Power: | Y, 500 W (RMS) / 4,000 W (peak to peak) |
| Frequencies Supported (kHz): | Traditional - 50/77/200; DownVu - 260 or 455 |
| Maximum Depth Capabilities: | Y, 2,300 ft. at 77 kHz, freshwater |
| Accepts MicroSD Card: | Y, for optional mapping and user data storage |
| NMEA 0183 Compatible: | Y, 1 input port/1 output port |
| AIS and DSC support: | Y, with NMEA 0183 |
| User Data Sharing Cable Compatible: | Y |
| Sonar History Rewind: | Y |
| Sonar Recording: | Y |
| Bottom Lock: | Y |
| Water Temperature Log/Graph: | Y |
| Tide Tables: | Y |
| Mounting Options: | Bail/Flush |
| Gift Box Dimensions: | 11.5" x 8.2" x 6.7" (291 x 209 x 170 mm) |
Features of Garmin echoMAP Scanning Sonar 55DV with Transducer:
- Easy to install and easy to use
- Sunlight readable screen with auto-dimming display and backlit keypad
- Preloaded Canada LakeVu HD
- Built-in 500 W (RMS) traditional HD-ID sonar and DownVu scanning sonar capabilities that allows you to see up to 750 feet below your boat
- Quick release mount allows for quick install and removal
- 5 Hz Internal GPS that updates 5x a second
- Sonar recording can be saved and returned to on your home computer
- Sonar history rewind
- Ability to share user data between devices
- Additional maps and charts available
Package Contents:
- Garmin echoMAP Recording Sonar 55DV with Transducer
- echoMAP 55dv with Canada LakeVu HD
- Power/data cable
- Quick-release mount
- Flush mount
- Protective cover
- GT20-TM transducer (77/200kHz/DownVu, 4-pin)
- Trolling motor mount
- Hardware
- Documentation
Be the first to review this product
Garmin echoMAP Sonar 55DV with Transducer Unavailable & Discontinued Models
List of Unorderable Models
- Garmin echoMAP 55dv with Transducer 010-01385-00 , MPN: 010-01385-00 , UPC: 753759126575 , Code: GA-FH-010-1385-00
